MOXA ioLogik E2210 Active Ethernet I/O

MOXA ioLogik E2210 Active Ethernet I/O
Inputs and Outputs
Digital Inputs: 12 channels
Digital Outputs: 8 channels
Isolation: 3k VDC or 2k Vrms
Digital Input
Sensor Type: Wet Contact (NPN), Dry Contact
I/O Mode: DI or Event Counter
Dry Contact:
• On: short to GND
• Off: open
Wet Contact (DI to GND):
• On: 0 to 3 VDC
• Off: 10 to 30 VDC
Common Type: 12 points per COM
Counter Frequency: 900 Hz
Digital Filtering Time Interval: Software Configurable
Digital Output
Type: Sink
I/O Mode: DO or Pulse Output
Pulse Output Frequency: 1 kHz
Over-Voltage Protection: 45 VDC
Over-Current Protection: 2.6 A (4 channels @ 650 mA)
Over-Temperature Shutdown: 175°C (min.)
Current Rating: 200 mA per channel
Power Requirements
Input Voltage: 12 to 36 VDC
Input Current: 190 mA @ 24 VDC
MTBF (mean time between failures)
Time: 213,673 hrs
Database: Telcordia SR332
